本套設備是發往俄羅斯的移動砂金設備，本套沙金選礦設備具體請看以下介紹。

1、采用移動式，一部為移動滾筒篩分系統，另一部移動淘金車為移動離心淘金車作為精選用。

2、上料方式可以使用挖掘機或裝載機等多種上料方式。

3、移動靈活方便：采用可轉向設計，可以原地180度轉向。

4、底盤采用重型汽車底盤設計，工作穩定可靠。

5、絞洗筒內含四條鉸刀，對于物料清洗更加徹底，提高工作效率。

6、針對供水系統進行了優化：
   上料斗內部沖水負責首次沖洗物料并且推送物料進入滾筒篩內；
   滾筒篩中央沖水負責對物料進行主要的沖洗工作；
   滾筒篩側沖水負責沖洗滾筒篩外部細篩網，防止堵孔。

7、集成度高，本輛移動淘金車集成了臥式全自動排礦離心機于一體，使用沙泵上料，4條機械支撐腿支撐，工作穩定可靠。(臥式離心機好處是轉子采用兩端固定，工作時穩定性好，適合用于移動設備上，立式離心機只能用于地面上，安裝時必須做硬化，尋找水平)

8、技術含量高：采用全自動排礦排礦臥式離心機等砂金設備配置,沙金提取設備,砂金提取設備選金設備提高回收率。

 Features

   This gold separating car including 2units,the 1st unit is gold trommel classifying unit car,the 2nd unit is movable centrifugal car to get gold concentrate.

   It can be easily feed by excavators or other types

   It can be easily moved&circled in 180 degree

   The base plate use heavy trailer type,good performance of steady and reliable work.

   The inner of reamer trommel screen including 4 reamers so it can be worked in high efficiency and make minerals more clean.

   Water supplying system: washing on top of hopper the then pushing the mixture to flow to the screen,washing in middle of screen which is the most principal,washing in screen outside it can clean the material carefully and avoid the gambling plug.

   The movable gold reamer trommel separating car with 1set horizontal auto discharge concentrator,feeding type is by 1set sand pump,with 4 mechanical holding frames,working in reliable and steady surroundings.(the horizontal concentrator is with spindle 2side fixed,it can a very good performance in jolting surroundings instead of vertical type which can only be used on ground level)

   It works well with high recovery with horizontal automatic discharge centrifuge concentrator.
